Textiles & Non-woven Textiles Digital Thickness Gauge
Standard Compliance
This digital thickness gauge adheres to internationally recognized standards for thickness measurement in textiles and non-woven materials. While the instrument itself does not fully comply with DIN, EN, or ISO certifications, its feeler geometry and applied pressure align with DIN EN ISO 5084, ensuring reliable results for materials requiring standardized testing. Additional referenced standards include ISO 9073-2, FZ/T 60004, and GB/T 24218.2, providing confidence in cross-industry compatibility.
Product Advantages
- Multi-Material Compatibility: Ideal for non-woven fabrics, textiles, felts, leather, paper, geomaterials, and more—a versatile solution for diverse industries.
- High Precision, Low Cost: Achieves 0.01 mm resolution and ±0.02 mm accuracy at an affordable price point, perfect for routine quality checks.
- Portable & Ergonomic: Compact design (230 g net weight) with a 40 mm jaw depth for easy handling in labs or production lines.
- Model Customization: Five specialized models (J-40-T, J-40-V, J-40-L, J-40-D1777-1, J-40-D1777-2) cater to specific materials and standards, from leather to coated fabrics.
- User-Friendly Interface: Digital LCD display with switchable mm/inch units and intuitive operation reduces human error.
Product Features
- Digital Display: Clear 4-digit, 8 mm tall LCD screen with selectable metric/imperial units.
- Model-Specific Configurations:
- J-40-T: Textiles/non-wovens, 50.42 mm feeler, 20 cm² area, 1 kPa pressure.
- J-40-V: Standard fleece, 56.42 mm feeler, 25 cm² area, 0.5 kPa pressure.
- J-40-L: Leather, 10 mm feeler, 0.785 cm² area, 49.1 kPa pressure.
- J-40-D1777-1 & -2: ASTM-compliant models for woven/knit fabrics and coated materials.
- Quick Comparison Tool: Low-cost design optimized for rapid thickness verification between batches.
- Durability: Robust construction with a 145 mm height profile for stability during measurements.
Technical Parameters
| Specification | Details |
|---|---|
| Measuring Range | 0–10 mm (standard) / 0–25 mm (optional) |
| Resolution | 0.01 mm (0.001 inch) |
| Accuracy | ±0.02 mm |
| Feeler Depth | 40 mm |
| Display | LCD, 8 mm digit height |
| Dimensions (L×W×H) | 103 × 65 × 145 mm |
| Weight | 230 g (net) / 800 g (gross) |
| Power | 1 × CR2032 3V lithium coin cell |
| Operating Conditions | 10–35°C, ≤85% RH (non-condensing) |
Why Choose This Gauge?
Ideal for manufacturers, labs, and QC teams needing reliable, budget-friendly thickness testing across textiles, non-wovens, and specialty materials. Its modular design and adherence to key standards ensure adaptability to global markets.
Upgrade your quality control process—contact us today for bulk pricing or custom configuration inquiries.
