Friction type fabric electrostatic performance tester is used to evaluate the electrostatic properties of fabrics or yarns and other materials after being charged by friction under laboratory conditions.

Instrument features.

1、Random display of peak voltage, half-life voltage and time.

2, the peak voltage automatically locked.

3, automatic measurement of half-life time.

Technical indicators.

1, electrostatic voltage test range: 0 ~ 10KV, accuracy: ≤ ± 1%

2, the specimen rotation line speed: 190 ± 10m / min, friction pressure added: 500cN

3, friction time: 0 ~ 999.9s adjustable (test set at 1min)

4, half-life time range: 0.1 ~ 59.9s adjustable

5, the size of the specimen: 80mm × 80mm four pieces, the size of the friction material: 200mm × 25mm

6, the host size: 450mm × 215mm × 260mm

7、Electrical control box size: 450mm×256mm×185mm

8、Working power: AC220V±10% 50Hz 200w

9, weight: about 50kg
