The XS(08)XG high modulus fibre strength tester is based on the old high modulus fibre strength tester with upgraded hardware and software, improved mechanical structure, improved drive method, smoother operation, more convenient operation, more accurate measurement of small forces and small displacements, and upgraded computer measurement software modules.

Overview：

【Applicable scope】：

Used for tensile physical properties testing of various fibers and metal extra fine wires and other materials.

Related standards】：

GB/T9997、GB/T14337、ISO5079、ISO11566

What are the features of XS(08)XG High Modulus Fiber Strength Tester?

●Sensitivity：0.01cN.

●Elongation resolution: 0.0001mm. 0.1um

●Operating mode: isometric elongation (CRE) principle.

●Motor servo drive and control, short response time.

●High-precision imported encoder makes position control more accurate without code leakage.

●High precision roller screw drive.

●Data sampling frequency greater than 1000Hz, more accurate measurement.

Self-editing parameters, free position control, free zero setting.

Up to seven hardware and software safety measures.

Digital force correction function.

●Full Chinese menu operation, blue screen LCD display, support on-line communication.

●Built-in 8 testing methods.

Automatic calculation of technical parameters such as fiber strength, intensity, modulus of elasticity and elongation.

Modular software design for stable and reliable operation, easy to upgrade.

XS(08)X is the ideal choice for mechanical testing laboratories of polymer materials, high performance fibres, carbon fibres, ceramic fibres, metal fibres, glass fibres, spandex, aramid fibres, etc. It is the ideal choice for colleges and research units.

It can be used in conjunction with our convenient operating software: XuSai_Test to easily display curves, print reports, export EXCEL files, and export various graphical storage methods. Generate standard database files to facilitate third party software processing of data by research units.
