The single wire and cable vertical burner is suitable for quality control/inspection units and wire and cable manufacturers for acceptance or qualification audits.

The standard recommends two types of flame calibration.

(1) Flame inner flame 50 ~ 60 mm, outer flame 170 ~ 190 mm

 (2) 10g copper head from 100℃ to 700℃ in 45±5S

If the user uses the flame verification method, the flame calibration device is required as an option. The flame calibration method will not be considered in the first phase of purchase, but can be added later if required.

I. Scope of application

The single wire and cable vertical combustion tester is designed to evaluate the combustibility of single wires and cables with a conductor diameter greater than 0.8mm or a cross-sectional area of not less than 0.5mm2). It is suitable for research, production and quality control of electrical and electronic products and their components such as lighting equipment, low-voltage electrical appliances, household appliances, machine tools and appliances, motors, electric tools, electronic instruments, electrical instruments, electrical connections and accessories. This model adopts the product structure recommended in GB18380.12-2008 Appendix B on the air mixing structure part, and the details also fully meet the acceptance requirements of quality inspection units.

Second, the product function characteristics

Single wire and cable vertical burning test is to use the specified size of Bunsen burner and a specific gas source (propane), according to a certain flame height and a certain angle of flame application on the vertical state of the test product timed to ignite, burning duration and burning length to assess its flammability and fire risk.

3. Related Technical Parameters

1. seven-inch full-colour programmable controller touch screen + PLC control, to achieve control / detection / calculation / data display multi-function

2. high degree of automation: automatic recording of test time, automatic display of test results, automatic timing, automatic ignition, automatic return of the Bunsen burner after the flame is applied, and the option of whether to turn off the gas

3. automatic ignition can be selected when starting; start, stop, gas, timing, ignition, save, save and exhaust are all controlled by the touch screen, the test can be completed with the touch of a fingertip

4. Timer button with PLC to automatically record the storage time of combustion consumption

5. The test time is automatically recorded by the system and the test results are generated

6. Burner: Φ12mm ± 0.5mm internal diameter

7. test inclination: 45° sample beam can be moved back and forth to adjust the position with the Bunsen burner according to the thickness of the sample.

8. Flame height: 20mm ± 2mm to 190mm ± 1mm adjustable

9. Flame application time: 0-999.9s ± 0.1s adjustable

10. combustion gas: 95% propane gas (LPG can be substituted in general)

11. gas: high purity propane gas or LPG (Note: gas source and link head user to provide)

12. length of wire and cable under test: 600±25mm.

13. the outer diameter of the wire and cable being tested: conductor diameter greater than 0.8mm or cross-sectional area greater than 0.5mm2

14. the device should be placed in a non-ventilated and temperature (23 ± 10) ℃ environment for the test

15. standard power of burning torch: 1KW. 16;

16. Power supply voltage: 220V/50Hz

17. gas flow rate: 0-1L/min

18. Air flow: 1.5-15L/min

19. Case material: steel plate electrostatic spraying (stainless steel case can be specified)

20. Equipment size: length 60 cm width 45 cm height 156 cm

IV. Applicable standards

GB/T18380.1-2008, GB/T18380.11-2008, GB/T18380.12-2008, GB/T18380.21-2008

GB/T18380.21-2008, GB/T18380.22-2008

Applicable standards: IEC60332, GB/T19666-2005, GB12972, GB13033, MT818, MT386, ISO5656
