Power Loom (with Drop Box & Dobby) G-PL190


Power Loom with Drop Box & Dobby is a high-performance weaving machine designed for producing a wide range of fabric patterns with precision and efficiency. Equipped with drop box and dobby mechanisms, it enables flexible multi-color weft insertion and complex weave designs. The machine ensures stable operation, high productivity, and consistent fabric quality, making it ideal for modern textile weaving applications.

Specification

Machine Type

Semi-Automatic Drop Box Looms

Reed Space

52

Shuttle Box

2 × 1

Shedding

12 shaft double lift dobby (Horizontal)

Reed

Fast Reed / Loose Reed (Optional)

Let Off

Semi-positive type let-off (Either attached beam type or separate beam type)

Take Up

Pickle’s seven wheel take-up mechanism

Picking

Under pick / Over pick motion

Speed

130–150 R.P.M (Depends on yarn type and quality)

Drive

1 HP loom motor

Lubrication

Centralized lubrication system

Warp Stop Motion

Electrical or Mechanical warp stop

Weft Stop Motion

Weft fork system or electronic Infra-red filler system

Accessories

Required accessories with standard accessories included

Warranty

One year warranty
