The Multi-function Burling Machine is a textile finishing machine designed to remove loose yarns, knots, slubs, lint, and other fabric defects. It supports multiple burling operations and helps improve fabric appearance, cleanliness, and finishing quality.

Basic characteristics

Features and function

1、Automatically roll-up(roll up by friction), automaticallyloosen fabric

2、Automatic infrared edging,edging error 5-8mm (error isdetermined by the situation of selvage)

3、Electronic automatic counting of length, and randomregulation of displayed meters and yards

4、Upper and lower inspection light boxes. Inspection panelof the lower light box with high-quality acrylic panels andground glass complex, which can not only relieve eyefatigue of the operator,and but also greatly reduce staticelectricity. Lamp source configuration adopts LED,lampsource brightness is strong and even, and mainly noshadow.

5、No-fabric pause function: Control by electronic eye,automatically stop running after loosening the cloth. Endcloth shall not slide down suddenly,remained cloth canconnect with second roll of cloth, in this way, it can savetime of placing the cloth again.

6、Install roller scutching axle so as to get better rolling effecton fabric.

7、Double-frequency speed control function is to keepbalanced working speed of releasing and rolling cloth so

8、as to achieve better rolling-up effect.

9、Specially install automatic regulation of tension function soas to make no easy deformation of width after finishing therolling of large elastic fabric, present natural status to bemore convenient for storage.

Auxiliary function

1、Adopt the function of plate-type scutching axle, thin-typeand easy wrinkle fabric take good effect,rolled fabric iscompact and leveling, not easy to produce dead wrinkle.

2、Microcomputer roller scutching axle is specific to fabricwith natural edge curling(for example: shirt cloth), rolledfabric after using shall not form the shape like barbell.

3、Install weighing function, weight scope is within 150KG

4、Equip with arch bar, when rolling the cloth, it canautomatically spread the cloth towards two sides by thebar,help to spread follow-up fabric

5、Fabric spreading position behind the machine installsscutching axle to be helpful to spread out greige cloth andscattered cloth, and facillitates to inspect fabric

6、Equip with height cut-off knife.

FAQs

1. What is a Multi-function Burling Machine used for?

It is used to remove yarn defects, loose fibers, knots, and other imperfections from fabrics.

2. What types of fabrics can it process?

It can process various woven and knitted fabrics, depending on the machine configuration.

3. What are the main advantages?

It improves fabric appearance, reduces manual work, and increases finishing efficiency.

4. Is the machine suitable for different burling operations?

Yes, its multi-function design allows it to handle different fabric finishing requirements.

5. Where is it commonly used?

It is widely used in textile mills, fabric finishing plants, garment factories, and quality control departments.
